Pyspark load and transform guidewire table with it's datatype autodetecting capacity

Continue from blog post -->

Guidewire Self Managed version H2 Tables ingest into Databricks Delta Tables

Published Notebook for PySpark will load Guidewire CSV files and then create delta tables based on auto-detecting datatypes and then finally all the load and transformation Process also creating in separate delta file processing log table final steps

Here is the Code available on databricks

Create New Guidewire Claim Tables from CSV File Auto-Detect Data Type V1.0 Template

Code logic below

1. Create New Guidewire Claim Tables from CSV File Auto-Detect Data Type V1.0 Template

from pyspark.sql import SparkSession

from pyspark.sql.types import StringType, IntegerType, FloatType, BooleanType, TimestampType

from pyspark.sql.utils import AnalysisException

# Initialize Spark session (already initialized in Databricks)

spark = SparkSession.builder.getOrCreate()

# Define the new database name

new_database = "gw_claimcenter_raw_db_2"

# Step 1: Create a new database if it doesn't exist

spark.sql(f"CREATE DATABASE IF NOT EXISTS {new_database}")

# Define the base path for FileStore

base_path = "dbfs:/FileStore/"

# List all CSV files that start with 'clm_' using dbutils

csv_files = [f.path for f in dbutils.fs.ls(base_path) if f.name.startswith("clm_") and f.name.endswith(".csv")]

# Initialize a list to store detailed log information

log_data = []

# Loop through each CSV file and infer schema

for file_path in csv_files:

    # Extract the file name from the file path

    file_name = file_path.split("/")[-1]

    table_name = file_name.replace(".csv", "")



    # Read the CSV file with schema inference

    try:

        df = spark.read.format("csv").option("header", "true").option("inferSchema", "true").load(file_path)

        read_status = "Success"

    except Exception as e:

        read_status = f"Failed: {e}"

        log_data.append((file_name, table_name, read_status, None, None))

        print(f"File '{file_name}' read failed: {e}")

        continue  # Skip to the next file if reading fails

    # Initialize column definitions for table creation

    column_defs = []

    column_info = []  # For detailed logging

    # Loop through inferred schema fields and build column definitions

    for field in df.schema.fields:

        field_name = field.name

        field_type = field.dataType

        # Map PySpark data types to SQL data types

        if isinstance(field_type, IntegerType):

            sql_type = "INT"

        elif isinstance(field_type, FloatType):

            sql_type = "FLOAT"

        elif isinstance(field_type, BooleanType):

            sql_type = "BOOLEAN"

        elif isinstance(field_type, TimestampType):

            sql_type = "TIMESTAMP"

        else:

            sql_type = "STRING"



        # Ensure column names are properly quoted

        column_defs.append(f"`{field_name}` {sql_type}")

        column_info.append((field_name, sql_type, "PRIMARY KEY" if field_name == "ID" else "NULL"))

    # Print inferred column information

    print(f"\nFile '{file_name}' column info: {column_info}\n")

    # Set ID column as primary key if it exists

    if 'ID' in df.columns:

        column_defs = [col_def.replace("`ID` INT", "`ID` INT PRIMARY KEY") for col_def in column_defs]

    # Combine column definitions into a single string for SQL

    column_defs_str = ", ".join(column_defs)

    # Create table in the new database

    try:

        # Create an empty Delta table using the DataFrame schema

        df.limit(0).write.format("delta").mode("overwrite").saveAsTable(f"{new_database}.{table_name}")



        # Insert data into the newly created Delta table

        df.write.format("delta").mode("overwrite").saveAsTable(f"{new_database}.{table_name}")

        # Log the success for the file

        create_status = "Success"

        print(f"Table '{table_name}' created successfully.")

    except AnalysisException as ae:

        create_status = f"Failed: {ae.desc}"

        print(f"Table '{table_name}' creation failed: {ae.desc}")

    except Exception as e:

        create_status = f"Failed: {e}"

        print(f"Table '{table_name}' creation failed: {e}")

    # Log the details for the file

    log_data.append((file_name, table_name, read_status, create_status, str(column_info)))

# Step 5: Create a log DataFrame to store the detailed log information

log_schema = ["FileName", "TableName", "ReadStatus", "CreateStatus", "ColumnInfo"]

log_df = spark.createDataFrame(log_data, log_schema)

# Save the log table in the new database

log_table_name = "file_processing_log"

log_df.write.format("delta").mode("overwrite").saveAsTable(f"{new_database}.{log_table_name}")

# Display the final log information

print("\nFinal Log Table Information:")

log_df.show(truncate=False)

# Also display the log table from the database

print("\nFinal Log Table from Database:")

spark.sql(f"SELECT * FROM {new_database}.{log_table_name}").show(truncate=False)

2. Found ID has some Null values in each tables doing data cleaning

from pyspark.sql.utils import AnalysisException

# Define the source and target database names

source_database = "gw_claimcenter_raw_db_2"

target_database = "gw_claimcenter_cleaned_db_2"

# Step 1: Create the target database if it doesn't exist

spark.sql(f"CREATE DATABASE IF NOT EXISTS {target_database}")

# Fetch list of tables in the source database

tables_list = spark.catalog.listTables(source_database)

# Loop through each table and filter rows where ID is not NULL

for table in tables_list:

    table_name = table.name

    source_table_name = f"{source_database}.{table_name}"

    target_table_name = f"{target_database}.{table_name}"

    try:

        # Read the existing Delta table into a DataFrame

        df = spark.table(source_table_name)

        # Check if 'ID' column exists in the DataFrame

        if 'ID' in df.columns:

            # Filter out rows where 'ID' is NULL

            df_filtered = df.filter(df['ID'].isNotNull())

            # Overwrite the target table with the filtered DataFrame

            df_filtered.write.format("delta").mode("overwrite").saveAsTable(target_table_name)

            print(f"Delta table '{target_table_name}' overwritten successfully with non-NULL 'ID' rows.")

        else:

            print(f"Table '{table_name}' does not have an 'ID' column, skipping.")



    except AnalysisException as ae:

        print(f"Error processing table '{table_name}': {ae.desc}")

    except Exception as e:

        print(f"Error processing table '{table_name}': {e}")

# Display a final message

print("\nOverwriting of Delta tables with non-NULL 'ID' rows completed.")
